Modelling and Simulations of SRM Drive

Modelling and Simulations of SRM Drive

Learn simulation of SRM drive like a hands-on MATLAB workshop (Specially for Research Scholar)

Instructor: Dr. Jignesh MakwanaLanguage: English

Pay one last time | Join Lifetime Membership

About the course

Switched reluctance motor (SRM) offers many advantages over other motors mainly for their simple mechanical structure and magnetless operation. After first demonstration in mid 18’s, SRM not only survived but also gaining interest exponentially amongst researchers due to availability of advanced, sophisticated and economical power electronics devices. Global interest of energy efficient transportation system is the main reason for current hike in the research trend of SRM and considered as best suitable energy efficient and cost effective motor to power electric vehicles.

MATLAB Simulation plays a very important role in the research and development of engineering projects, products and system. It helps predicting performance of the system, to validate control strategies and saves the time of product development.


I am Dr. Jignesh Makwana, started working on SRM in 2005 and then I have published numbers of research paper and book chapters in reputed IEEE conferences and SCI journals. I completed my Phd on Switched Reluctance Motor from prestigious Indian Institute of Technology Roorkee (IIT Roorkee) in 2013.I provided consultancy to several industries for design and development of SRM drive. I came with this course to help students who wish to work with SRM for their dissertation or project work.

This course includes all the necessary detail required to design and develop simulation model of SRM Drive. It explains and compares different non-linear mathematical modelling techniques to model SRM. MATLAB simulations of SRM & drive have been explained step by step including motor model, commutation pulse generation, current control, voltage pwm control, speed control techniques, closed loop control techniques, load characteristics, electric & regenerative braking and more. All these simulation models have been developed runtime to have learning experience like hands-on MATLAB workshop instead of just power point presentation. Have a look at the course contents and join the course.



When does the course start and finish?

The course starts now and never ends! It is a completely self-paced online course - you decide when you start and when you finish.

How long do I have access to the course?

How does lifetime access sound? After enrolling, you have unlimited access to this course for as long as you like - across any and all devices you own.

What if I am unhappy with the course?

We would never want you to be unhappy! If you are unsatisfied with your purchase, contact us in the first 30 days and we will give you a full refund.

Reviews and Testimonials

See what others have to say


Até o momento está bastante interessante.

By Carlos Eduardo Mendes do Carmo


I love the way sir explains. Its very clear

By Basavaraju S Hadapad


A very knowledgeable and fantastic sessions with brilliant explanation of concepts.

By Sonika Sonika
